FX-207 PBX System
FX-207 PBX System is feature rich telephone exchange system using regular house phone
FOR HOME
FOR OFFICE
FOR HOME OFFICE
Auto Attendant FAX Auto Switch Remote Appliance Control Call Management / Report Toll Restriction Doorphone interface
FX-207 is the best low cost, high quality PABX for today's telecommunication needs. It
offers most of the features available in much more expensive PBX units without using any
high-priced KEY PHONE unit.
The special voice feature allows you to record your own greeting to direct outside
callers. No telephone operator is needed. Whether for a home or a small business, its
money saving pays for itself almost immediately.
Special Features:
Announce user pre-recorded, digitized greeting to direct calls Route FAX calls to uses FAX machine automatically Control appliance through telephone from remote or local location Provide computer or printer interface for call report and management Support both Touch Tone and Rotary phones, no key-phone needed Ring all extensions prevents loss of important calls Provide doorphone capability for entrance control Support multiple phone equipment on a single extension Use minimum mechanical components to obtain higher reliability
PBX Functions:
Call Transfer, Conference call and Splitting call Call pickup and Call waiting Ring back feature reminding a party still on-hold Toll restriction saving long distance toll charge Password protection preventing unauthorized access Data line integrity for FAX and computer communication Do not Disturb function individually programmable
System Features:
Expand two outside lines to seven extensions Work with most Faxes and answering machines Provide Interface for music-on-hold feature Supply different ring patterns for outside and inside calls Preserve minimum communication during power failure Retain FLASH signal for external PBX or phone company
Specifications:
Capacity | 2 outside, 7 inside |
Power Supply | 2 Models available AC 110 Volt
and AC 220 Volt, 50/60 Hz |
Dialing | 10 PPS for pulse / DTMF Touch Tone |
Ring | 60-70 Vrms at 20 Hz |
Flash Timing | 600msec |
Music Input | 500mV maximum |
Applance Load | 5A maximum |
Serial Communication | RS-232, 1200 baud 8N1 |
Connector | RJ-11 for phone / DB-9 for serial port |
Dimensions | 9.5 in. x 11.6 in. x 3 in. |
|
